M5Stack 24AWG 4-Core Shielded Twisted Pair Cable (0.5m)
$3.03
Description
Description
- 1x M5Stack 24AWG 4-Core Shielded Twisted Pair Cable (0.5m)
Size
- Cable length: 0.5 meter
Electrical
- Working voltage: 2.5 ~ 9 V
- Working current: <1800 mA
- Loop voltage drop: less than 0.5 V
- Contact resistance: 5 mΩ
- Contact rated current: 1.8 A
- Withstand voltage: AC 250 V
- Data transfer rate: minimum 425 mb/S
Environmental
- Working temperature: -10°C ~ +50 °C
- Storage temperature: -10 ~ +35 °C
- Working humidity: <55 %
- Humidity range: 25 % R.H~90 % R.H
Wire
- Conductor: (11/0.16+4C), bare copper + aluminum foil + braid
- Insulation TPE OD = 0.90 ±0.05 mm, core wire color: black, white, green, red
- Wire: Outer diameter 5.0
- Composition of each bare copper wire
- Outer cover: TPE, black, OD: 5.0
- Wire, plug, and mechanical characteristics requirements MAX; contact pull-out force: 50g MIN
- Weight: 11.89 g
