Seeedstudio FluxNode SenseCAP M4 Square High Performance IoT Device
$361.79
Description
- Seeedstudio FluxNode SenseCAP M4 Square High Performance IoT Device
- Supports potential extensions for web3.0 dAPPs
- Equipped with Intel Celeron J4125 and ECC608 crypto chip
- Offers comprehensive cloud service for device management
- Energy efficient with a low power consumption rate
The Seeedstudio FluxNode SenseCAP M4 Square High Performance IoT Device is an advanced piece of technology powered by FluxOS. It is designed to support potential extensions for other Web 3.0 dAPPs. This device offers a seamless, no-code experience, enabling users to complete the deployment of CUMULUS FluxNode in just four steps.
The FluxNode SenseCAP M4 Square supports a variety of applications provided by SenseCAP, all accessible from the dApp center. This device also offers a comprehensive cloud service, assisting users in the purchase, deployment, management, and monitoring of their devices.
The device is powered by an Intel Celeron J4125, with a frequency range of 2.0 – 2.7GHz, and is equipped with 4 cores and 4 threads. It also features a built-in TPM2.0 cryptographic processor and an ECC608 crypto chip, ensuring high-security authentication and reliable connectivity.
Despite its powerful capabilities, the FluxNode SenseCAP M4 Square is energy efficient, with a low power consumption rate. The device has received FCC and CE certification, attesting to its compliance with safety and performance standards.
Please note that the device’s power consumption rate is approximately 10W or 7.2 kWh per month.
- 1x SenseCAP M4 Square
- 1x User Manual
- 1x International Power Adapter
- 2x SenseCAP Sticker
- 130 x 120 x 50 mm
- Components: SenseCAP M4 Square
- Processor: Intel Celeron J4125 (Frequency: 2.0 – 2.7GHz)
- Coprocessor: Raspberry pi at RP2040 32bit Dual-core Arm Cortex M0+
- Graphics: Intel UHD Graphics 600 (Frequency: 250 – 750 MHz)
- Memory: LPDDR4 8 GB
- Storage: Internal 512 GB SSD
- Wireless: Wi-Fi 802.11 a/b/g/n/ac at 2.4/5 GHz HT160
- Networking: Intel226-V PCIe2.5GbE LAN, Supports Wake-On-LAN, Supports PXE
- Audio: Microphone + headphone Combo Connector
- USB Ports: USB 2.0 Type-A x2, USB 3.1 Type-A x1, USB 3.1 Type-C x1
- Video Interfaces: HDMI2.0a: Up to 4096×2160 at 60Hz 24bpp / DP1.2a: Up to 4096×2160 at 60Hz 24bpp
- Expansion Slots: M.2(Key B, 2242/2280): SATA III, USB2.0, UIM; M.2 (Key M, 2242/2280): PCIe 2.0 ×4; Micro SD card Socket; SIM Card Socket; SATA III
- Operating temperature: 0～45 °C
- Storage temperature: -20～60 °C
- TPM: Built-in TPM 2.0
- Power: DC Jack 5/2.1mm or Type-C PD; DC Jack input: 12-19V DC; Type-C input: 15V DC
