T506S Mini AI Computer w/ Jetson Xavier NX, 5x PoE RJ45, 128GB SSD, 4x USB 3.0
$1,934.79
Description
- Mini AI Computer T506S powered by Jetson Xavier NX
- Versatile I/O options: 5x PoE RJ45, 128GB SSD, 4x USB 3.0, RS232/485
- Robust AI performance
- Durable IP55 enclosure
- Expandable storage
The T506S Mini AI Computer w/ Jetson Xavier NX, 5x PoE RJ45, 128GB SSD, 4x USB 3.0, RS232/485 is an advanced edge AI platform equipped with the Jetson Xavier NX processor. This device is designed to facilitate intelligent industrial applications and autonomous machinery. The unit is encased in a fanless aluminum alloy enclosure with an IP55 grade, ensuring durability and reliability in various environments. It is capable of operating on a wide voltage range of 12-36 V.
The system boasts hybrid network access capabilities, including Gigabit network ports with Power over Ethernet (PoE) support, and is compatible with Wi-Fi, 4G, and 5G wireless modules, as well as GPS navigation, although these modules are not included. The computer offers a plethora of I/O options to cater to diverse operational needs and is particularly adept at local video analytics due to its onboard SSD and storage expandability. It comes pre-installed with JetPack 4.6, which supports a comprehensive software stack and various development tools from the Seeed Edge AI ecosystem partners.
This Mini AI Computer is adept for deployment in a range of scenarios, including smart city infrastructure such as traffic management and parking monitoring, industrial automation, workplace safety, preventive maintenance, retail analytics, digital signage, and healthcare applications like mask detection.
Please note that wireless modules for Wi-Fi, 5G, 4G, and GPS navigation are not included with the device and must be acquired separately.
- 1x Mini AI Computer T506S
- 1x DIO Extension Plug
- 1x Mounting Bracket
- 1x 19V Power Adapter (without power cord)
- 1x Power Adapter Cable
- 155 x 165 x 52.5 mm
- Module: NVIDIA JETSON XAVIER NX
- AI Performance: 21 TOPs(INT8)
- CPU: 6-core 64-bit CPU, NVIDIA Carmel ARMv8.2
- GPU: 384-core NVIDIA Volta GPU
- Memory: 8 GB 128-bit LPDDR4x 59.7 GB/s
- Storage: 1x 128GB SSD pre-installed via the M.2 Key M NVMe 2280 interface, 1xTF Slot
- Display: 1x HDMI Type A
- Video decoder:
- 2x 4K @ 60 | 4x 4K @ 30 | 12x 1080p @ 60 | 32x 1080p @ 30 (H.265)
- 2x 4K @ 30 | 6x 1080p @ 60 | 16x 1080p @ 30 (H.264)
- Gigabit Ethernet: 5×RJ45 Gigabit Network port, (4xPoE(PSE) GbE Ports, 1xPoE(PD) GbE Port)
- OS: Pre-installed JetPack 4.6
- Wifi/BLE: Surface Mounted – support WiFi (modules not included)
- Network: mini PCIe – support 4G (modules not included), M.2 E Key – Support 5G (modules not included)
- GPS: Support GPS (modules not included)
- USB: 4x USB 3.0 Type A Connector; 1x Micro-USB port for Device mode
- Industrial Interfaces:
- 1x CAN 2.0b, With CAN chip
- 1x I2CÂ
- 4x GPIO
- 1x RS232Â Â Â
- 1x RS485
- RTC: 1x RTC Connector with Rechargeable Battery
- FAN: 1x FAN connector
- LED: 2x LED STATE
- Key: Reset KEY, Recovery KEY
- Power: 12-36V DC
- Mechanical:
- 1.5 kg
- -20 to 65 °C
- 10%-90% non-condensing
