Waveshare CP2102 USB UART Board (mini)

• 1x Waveshare CP2102 USB UART Board (mini)
• 2x 4-pin male pinheader
• 2x 4-pin female pinheader
• 1x 6-pin custom connector jumper wire

Website

• Single-chip USB to UART data transfer
• No external resistors or crystal required
• On-chip power-on reset circuit and voltage regulator
• Integrated 1024-byte EEPROM
• USB function controller
• Compliant with USB Specification 2.0; full-speed (12 Mbps)
• USB suspend states supported via SUSPEND pins
• UART supports all handshaking and modem interface signals
• Supported data formats: Data bits: 5, 6, 7, 8; Stop bits: 1.5, 2; Parity: odd, even, none
• Baud rates range from 300 bps to 1 Mbit
• 576-byte receive buffer; 640-byte transmit buffer
• Supports hardware or X-On/X-Off handshaking
• Event character support
• Virtual COM port device drivers for Windows 8/7/Vista/Server 2003/XP/2000, Mac OS-X/OS-9, Linux 2.40 or higher
• USBXpress direct driver support for Windows 7/Vista/Server 2003/XP/2000, Windows CE
• Operating temperature range: –40 to +85 °C
• Supports Mac, Linux, Android, WinCE, Windows 7/8.1/10/11
• Voltage output support: 5V or 3.3V
• Integrated USB protection device: SP0503
• Equipped with 3 LEDs: TXD LED, RXD LED, POWER LED
• Pins accessible on pin headers: TXD, RXD, RTS, CTS
• Other pins accessible on drilled holes, easily connected to user application system (separate pin headers provided)
