Waveshare Quectel RM520N-GL IoT 5G Global Band Module, 5G Sub-6GHz, M.2 Form Factor W/ 3GPP 5G Release 16 Spec

• Waveshare Quectel RM520N-GL IoT 5G Global Band Module, 5G Sub-6GHz, M.2 Form Factor W/ 3GPP 5G Release 16 Spec
• Supports 5G, 4G, and 3G networks
• Integrates high-precision GNSS receiver
• Optimizes for eMBB and IoT applications
• Ensures global carrier compatibility
• Supports multi-OS drivers including Windows and Linux

The Waveshare Quectel RM520N-GL IoT 5G Global Band Module, 5G Sub-6GHz, M.2 Form Factor W/ 3GPP 5G Release 16 Spec is a sophisticated 5G module optimized for Internet of Things (IoT) and Enhanced Mobile Broadband (eMBB) applications. It adheres to the 3GPP Release 16 specification and supports both non-standalone (NSA) and standalone (SA) 5G modes. The module is designed in an M.2 form factor, ensuring compatibility with various Quectel 5G and LTE-A modules, which facilitates seamless migration from LTE-A to 5G technology. This industrial-grade module is intended for use in both industrial and commercial applications.

The RM520N-GL series is engineered to be compatible with nearly all mainstream carriers globally. It features an integrated multi-constellation high-precision GNSS receiver, supporting GPS, GLONASS, BDS, and Galileo systems, which enhances product design by providing rapid and precise positioning capabilities.

This module incorporates a comprehensive set of network protocols and integrates multiple industry-standard interfaces. It supports a variety of drivers and software functions, including USB and PCIe drivers for Windows, Linux, and Android operating systems. This versatility makes it suitable for a wide range of eMBB and IoT applications, such as industrial routers, home gateways, set-top boxes, industrial and consumer laptops, industrial PDAs, rugged tablet PCs, video surveillance systems, and digital signage.

The module supports 5G, 4G, and 3G networks, offering full coverage of multi-network standards. It is equipped with a multi-constellation GNSS receiver for applications that require fast and accurate positioning in diverse environments. Additionally, it supports various functionalities, including DFOTA and optional VoLTE, in alignment with the 3GPP Release 16 standards.
